9 Powerful Instruments

• Arbitrary Waveform Generator
• Data Logger
• Frequency Response Analyzer
• Lock-in Amplifier
• Oscilloscope
• Phasemeter
• PID Controller
• Spectrum Analyzer
• Waveform Generator

   Hardware Highlights

• Exceptional low-frequency noise performance: 500 µV RMS noise at full input bandwidth
• 0.3 ppm stability onboard clock
• < 650 ns input to output latency

   Applications

• High speed data logging
• Automated test sequence
• System prototyping and simulation
• Closed loop control design
• Optical metrology and spectroscopy
• Control hub for optical, imaging, and other custom-made systems
• Quantum computing

Specifications

Four Analog Inputs

• 10-bit and 18-bit ADCs with frequency- dependent blending
• 5 GSa/s sampling rate with 1 channel, 1.25 GSa/s with 4 channels
• Input noise: 30 nV/√Hz at 100 Hz
• User selectable 300/600 MHz analog bandwidth
• AC or DC coupling, 50 Ω or 1 MΩ input impedance
• 400 mVpp, 4 Vpp, or 40 Vpp input range

Four Analog Outputs

• 16 bit, 1.25 GSa/s DACs
• ± 1 V up to 500 MHz, ± 5 V up to 100 MHz

Additional I/O

• Dedicated trigger input
• 10 MHz reference input and output
• Onboard Wi-Fi, Ethernet, and USB-C
• 120 GB high-speed SSD

Programming Environment

• API support for Python and MATLAB
• Class-leading, multi-touch user interface
