Detail

Frequency

Bandwidth Options

DANL @1 GHz

Overall Amplitude Accuracy

Phase Noise @1 GHz (10 kHz offset)

N9000B

N9000B CXA Signal Analyzer, 9 kHz to 26.5 GHz

9 kHz to 26.5 GHz

10 standard, 25 MHz

-163 dBm

±0.50 dB

-110 dBc/Hz

N9010B

N9010B EXA Signal Analyzer, 10 Hz to 44 GHz

10 Hz to 44 GHz

10 standard, 25, 40 MHz

-170 dBm

±0.27 dB

-109 dBc/Hz

N9020B

N9020B MXA Signal Analyzer, 10 Hz to 50 GHz

10 Hz to 50 GHz

25 standard, 40, 85, 125, 160 MHz

-172 dBm

±0.23 dB

-114 dBc/Hz

N9021B

N9021B MXA Signal Analyzer, 10 Hz to 50 GHz

10 Hz to 50 GHz

255, 510 MHz

-172 dBm

±0.19 dB

-130 dBc/Hz

N9030B

N9030B PXA Signal Analyzer, 2 Hz to 50 GHz

2 Hz to 50 GHz

25 standard, 40, 85, 125, 160, 255, 510 MHz

-174 dBm

±0.19 dB

-136 dBc/Hz

N9032B

N9032B PXA Signal Analyzer, 2 Hz to 26.5 GHz

2 Hz to 26.5 GHz

1, 1.5, and 2 GHz

-174 dBm

n/a

-136 dBc/Hz

N9040B

N9040B UXA Signal Analyzer, 2 Hz to 50 GHz

2 Hz to 50 GHz

25 standard, 40, 255, 510 MHz, 1 GHz

-174 dBm

±0.16 dB

-135 dBc/Hz

N9041B

N9041B UXA Signal Analyzer, 2 Hz to 110 GHz

2 Hz to 110 GHz

25 MHz standard, 40 MHz, 1 GHz

-174 dBm

±0.16 dB

-135 dBc/Hz

N9042B

N9042B UXA Signal Analyzer, 2 Hz to 110 GHz

2 Hz to 50 GHz, with V3050A 110 GHz

1, 1.5, 2, and 4 GHz

-174 dBm

± 0.24 dB

-135 dBc/Hz
